| Discontinued for reference only | |
|---|---|
 |
SYNCHRONOUS MOTORS: GA Series |
| HEAVY DUTY, REVERSIBLE HYSTERESIS SYNCHRONOUS | |
GA Series motors provide the highest torque ratings of all the Hurst gear motors - 600 oz-in at 1 RPM. A choice of 14 different speeds, from 1 RPM to 300 RPM, are available for operation at 115 VAC at 60 Hz. Other speeds may be specified on special order. High quality construction throughout assures dependable field performance. Click here for gear train construction details.
Heavy Duty Gearing
Gear trains for GA motors are rated for loads of up to 600 oz-in. The selection of materials and the design of each gear in the GA Series gear train is based on its position in the reduction sequence. This provides optimum performance for the unique speed and loading of each gear and overall balance of all compenents in the gear assembly. Models listed are designed for 115V, 60 Hz operation. A capacitor is required for operation.
| Model | Part Number |
Speed @ Output Shaft (rpm) |
Rated Pull-Out Torque (oz-in) |
Input Power (watts) |
Capacitor Value (MFD) |
Temp. Rise oC. Full Load |
Weight (oz) |
|---|---|---|---|---|---|---|---|
| GA | 992093 | 1 | 600 | 10 | 1.0 | 50 | 40 |
| GA | 992094 | 2 | 300 | 10 | 1.0 | 50 | 40 |
| GA | 992110 | 3 | 200 | 10 | 1.0 | 50 | 40 |
| GA | 992095 | 4 | 150 | 10 | 1.0 | 50 | 40 |
| GA | 992112 | 5 | 120 | 10 | 1.0 | 50 | 40 |
| GA | 992096 | 6 | 100 | 10 | 1.0 | 50 | 40 |
| GA | 992097 | 10 | 60 | 10 | 1.0 | 50 | 40 |
| GA | 992106 | 18 | 33.33 | 10 | 1.0 | 50 | 40 |
| GA | 992098 | 30 | 20 | 10 | 1.0 | 50 | 40 |
| GA | 992099 | 60 | 10 | 10 | 1.0 | 50 | 40 |
| GA | 992108 | 100 | 6 | 10 | 1.0 | 50 | 40 |
| GA | 992100 | 120 | 5 | 10 | 1.0 | 50 | 40 |
| GA | 992109 | 150 | 4 | 10 | 1.0 | 50 | 40 |
| GA | 992105 | 300 | 2 | 10 | 1.0 | 50 | 40 |
