| Material and Finish: |
|---|
| Insulator: | PBT or ABS glass filled Nylon or Polyester, UL 94V-0 rated. |
| Contact: | Phosphor Bronze, Gold over Nickel plated. |
| Shield: | Brass , Tin or Nickel plated |
| |
| Mechanical Specifications: |
|---|
| Operating Temperature: | 0°C to +70°C |
| |
| Electrical Specifications: |
|---|
| Current Rating: | 1 - 1.5 A |
| Voltage Rating: | 125 - 150VAC rms |
| Insulator Resistance: | 500 - 1000 Megaohm min. @ 500VDC |
| Dielectric Withstanding Voltage: | 1000 VAC for 1 minute |
| Contact Resistance: | 30 - 40 Milliohms max. |
|
