Power Dynamics, Inc.
I.D.C. Connectors
PDI-09RS-IB-H
(Shown)
Number of Pins
9
15
25
37
A
16.30
24.60
38.30
54.80
B
25.00
33.30
47.10
63.50
C
30.80
39.20
53.10
69.40
PDI-09SS-IB-H
(Shown)
Number of Pins
9
15
25
37
A
16.92
25.25
38.96
55.42
B
25.00
33.30
47.10
63.50
C
30.80
39.20
53.10
69.40
Click here for Specifications
Specifications subject to change without notice. Dimensions in mm.
