High density and reliability has made this connector a
standard for the electronic industry.
Both male and female have intermating bodies to prevent
misalignment or mismatching.
Male used on card edge with the female usually on the
Insulator: Glass-filled polyester.
Male pins - Brass.
Female pins - Phosphor bronze.
Plating: Gold flash in mating area, tin on solder tails.
(contact Beckwith Electronics for other plating options)
|R/A DIP Solder|
