Hirschmann


Laboratory Equipment 4 mm SLS 20 B
Description
Laboratory plug, protected against contact, may be made up into cables with screw connection up to 1.5 mm2 cross-section, insulated by latching and sprung insulating sleeve which is only released by pressure on the side-mounted locking spring. 4 mm diameter.

Rated voltage300 V =
Overvoltage category2
Pollution degree2
Rated current16 A
Volume resistance5 m Ohms
Temperature range-25°C...+80°C
Type of connectionscrewed
Packaging quantity50 pieces
Order No.931825-100 (black)
931825-101 (red)
