Laboratory Equipment 4 mm | SLS 10 B |
---|---|
Description Laboratory plug, protected against contact, may be made up into cables with solder connection for cross-sections up to 2.5 mm2, insulated by latching and sprung insulating sleeve which is only released by pressure on the side-mounted locking spring. 4 mm diameter. |
Rated voltage | 60 V DC |
Rated current | 30 A |
Volume resistance | 5 m Ohms |
Temperature range | -25°C...+80°C |
Type of connection | solder |
Packaging quantity | 50 pieces |
Order No. | 931824-100 (black) 931824-101 (red) |
