Hirschmann


Laboratory Equipment 4 mm PRUF 20
Description
Dual function test probe. The slender spring steel pin can penetrate insulation + oxide layers. The test probe can be plugged into a 4 mm diameter socket using the multiple-spring wire. 4 mm diameter socket connection.

Rated voltage60 V DC
Volume resistance15 m Ohms
Temperature range-25°C...+80°C
Type of connection4 mm diameter socket
Test proberigid
Packaging quantity20 pieces
Order No.973505-100 (black)
973505-101 (red)
