Safety Laboratory Equipment 4 mm | KLEPS 2800 |
---|---|
Description Safety clamp-type test probe with wide opening grip claws for contacting large measuring areas and leads with large cross-sections. 4 mm brass socket connection. Connects with safety measuring leads. |
Rated voltage | 1000 V = |
Overvoltage category | 3 |
Pollution degree | 2 |
Rated current | 20 A |
Volume resistance | 100 m Ohms |
Temperature range | -25°C...+80°C |
Type of connection | 4 mm socket |
Clamping range | Ø 10 mm |
Clamping type | grip claws |
Packaging quantity | 10 pieces |
Order No. | 972308-100 (black) 972308-101 (red) |
