SYNCHRONOUS MOTORS: CA Series |
| REVERSIBLE HYSTERESIS SYNCHRONOUS | |
Efficient, compact CA Series hysteresis synchronous motors have a range of standard speeds from 1200 RPM (direct drive) to 1/3 RPM (geared). Gear train materials include high quality bronze bearings, brass gears, hardened steel pinions and wheel shafts.
The gear torque rating is 100 oz-in at 1 RPM. All CA Series motores are reversible. Models listed are designed for 115V, 60 Hz operation of both motor and actuator. A capacitor is required for operation.
| Model | Part Number |
Speed @ Output Shaft (rpm) |
Rated Pull-Out Torque (oz-in) |
Input Power (watts) |
Capacitor Value (MFD) |
Temp. RiseoC. Full Load |
Weight (oz) |
|---|---|---|---|---|---|---|---|
| CA | 990272 | 1/3 | 100* | 5 | .50 | 40 | 15 |
| CA | 990341 | 1/2 | 100* | 5 | .50 | 40 | 15 |
| CA | 990338 | 1 | 100* | 5 | .50 | 40 | 15 |
| CA | 990275 | 2 | 50 | 5 | .50 | 40 | 15 |
| CA | 990357 | 3 | 33.33 | 5 | .50 | 40 | 15 |
| CA | 990280 | 4 | 25 | 5 | .50 | 40 | 15 |
| CA | 990282 | 5 | 20 | 5 | .50 | 40 | 15 |
| CA | 990356 | 6 | 16.67 | 5 | .50 | 40 | 15 |
| CA | 990298 | 8 | 12.50 | 5 | .50 | 40 | 15 |
| CA | 990285 | 10 | 10 | 5 | .50 | 40 | 15 |
| CA | 990287 | 12 | 8.33 | 5 | .50 | 40 | 15 |
| CA | 990332 | 15 | 6.66 | 5 | .50 | 40 | 15 |
| CA | 990353 | 20 | 5 | 5 | .50 | 40 | 15 |
| CA | 990311 | 30 | 3.33 | 5 | .50 | 40 | 15 |
| CA | 990290 | 40 | 2.50 | 5 | .50 | 40 | 15 |
| CA | 990314 | 60 | 1.67 | 5 | .50 | 40 | 15 |
| CA | 990294 | 120 | .83 | 5 | .50 | 40 | 15 |
| CA | 990323 | 150 | .67 | 5 | .50 | 40 | 15 |
| CA | 990295 | 200 | .50 | 5 | .50 | 40 | 15 |
| CA | 990296 | 240 | .42 | 5 | .50 | 40 | 15 |
| CA | 990316 | 400 | .25 | 5 | .50 | 40 | 15 |
| CA | 990317 | 600 | .17 | 5 | .50 | 40 | 15 |
| CA | 991194 | 1200* | .10 | 5 | .50 | 40 | 15 |
